3644A/50 100 Cables, Wires |
|
Allicdata Part #: | 3644A/50100-ND |
Manufacturer Part#: |
3644A/50 100 |
Price: | $ 227.84 |
Product Category: | Cables, Wires |
Manufacturer: | 3M |
Short Description: | RND SHLD JCKT CBL 50 BLA 100' |
More Detail: | 50 (25 Pair Twisted) Conductor Multi-Pair Cable Bl... |
DataSheet: | 3644A/50 100 Datasheet/PDF |
Quantity: | 1000 |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
54 +: | $ 207.12800 |
Series: | 3644X |
Part Status: | Active |
Lead Free Status / RoHS Status: | -- |
Cable Type: | Multi-Pair |
Moisture Sensitivity Level (MSL): | -- |
Number of Conductors: | 50 (25 Pair Twisted) |
Wire Gauge: | 28 AWG |
Conductor Strand: | 7/36 |
Conductor Material: | Copper, Tinned |
Jacket (Insulation) Material: | Poly-Vinyl Chloride (PVC) |
Jacket (Insulation) Diameter: | 0.320" (8.13mm) |
Shield Type: | Foil, Braid |
Length: | 100.0' (30.5m) |
Jacket Color: | Black |
Ratings: | -- |
Features: | -- |
Voltage: | 150V |
Operating Temperature: | -- |
Usage: | Communication, Computer, Control |
Jacket (Insulation) Thickness: | 0.0260" (0.660mm) |
Conductor Insulation: | Polyolefin (PO) |
Shield Material: | Aluminum; Copper, Tinned |
Shield Coverage: | 100%, 90% |
Due to market price fluctuations, if you need to purchase or consult the price. You can contact us or emial to us: sales@allicdata.com
Multiple Conductor Cables: 3644A/50 100 Application Field and Working Principle
Multiple conductor cables, commonly known as multicore cables, are electrical cables used to move electrical power and signals between two adjacent locations using multiple electrical conductors. They come in various sizes, designs, colors, and materials, making them well suited for numerous applications in the consumer, service, commercial, and industrial sectors.
In general, multiple conductor cables are composed of three or more insulated conductors, each surrounded by an independent sheath. The sheathing protects each wire, facilitates handling during installation, and helps to keep the wires apart to prevent short circuits. All wires are then compounded in a single cable.
3644A/50 100 is a type of multiple conductor cable. It comprises 100 conductors in a single cable set surrounded by a polyvinyl chloride (PVC) jacket. The PVC material provides insulation and helps to prevent dangerous electric shock and provides flexibility and high strength to the cable. Most notable of this cable type is its favorable noise-reduction properties, which make it suitable ion locations requiring high levels of audio signals. The twisted wires in the cable also lends it extra flexibility.
Due to its characteristics, multiple conductor cable 3644A/50 100 is widely used in different fields. Its flexibility and strong PVC material enables it to be used in educational, commercial, and industrial settings. It is most commonly used for cable harnesses, to help carry electronic signals and provide electrical insulation. Its thickness means it is well suited for communication, instrumentation, and power applications in category 5/5E systems.
Particularly, 3644A/50 100 cable is best suited for audio applications particularly in theater, studio, or post-production settings. The conductor material and its design, which includes twisted pairs and flexible sheath allows for efficient signal transmission. Additionally, the noise reduction capabilities of this type of cable reduces the effect of EMI (electro magnetic interference), to ensure clean and clear sound.
The working principle of multiple conductor cable 3644A/50 100 is simple. It is composed of one of more insulated conductors and a PVC sheathing. This PVC material provides electrical insulation and helps to reduce the stress placed on the wire during installation. As the cable is bent in-situ, the sheathing helps to keep the wires apart to prevent them from becoming too close and causing an electrical short circuit. The wire is then compounded in the PVC sheath, to ensure the safety of the wires in the cable, and enable the cable to carry signals and electrical power:
The electrical power is transferred from one point to another via the bare conductors contained inside the PVC sheath. They create electrical paths that provide a direct connection from source to destination. The Twisted wires in the cable also reduce noise, thus producing better audio and video signals.
Multiple conductor cable 3644A/50 100 is widely used in many applications, due to its flexibility and robustness. It is perfect for the transmission of electrical power, and can also be used in audio systems for cleaner sound and reduced interference. By following the working principle, it can be concluded that this type of cable is efficient and useful in numerous situations.
The specific data is subject to PDF, and the above content is for reference
