MENB1010A2403F01 Allicdata Electronics
Allicdata Part #:

271-2740-ND

Manufacturer Part#:

MENB1010A2403F01

Price: $ 7.44
Product Category:

Power Supplies - External/Internal (Off-Board)

Manufacturer: SL Power Electronics Manufacture of Condor/Ault Brands
Short Description: AC/DC DESKTOP ADAPTER 24V 10W
More Detail: 24V 12W AC/DC External Desktop (Class I) Adapter C...
DataSheet: MENB1010A2403F01 datasheetMENB1010A2403F01 Datasheet/PDF
Quantity: 1000
250 +: $ 6.76658
Stock 1000Can Ship Immediately
$ 7.44
Specifications
Series: MENB1010
Part Status: Not For New Designs
Region Utilized: International
Form: Desktop (Class I)
Input Type: Cord (Sold Separately)
Voltage - Input: 100 ~ 240 VAC
Voltage - Output: 24V
Current - Output (Max): 500mA
Power (Watts): 12W
No Load Power Consumption: 300mW (Max)
Polarization: Positive Center
Applications: Medical
Efficiency: Level V
Operating Temperature: 0°C ~ 40°C
Output Connector: Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm
Size / Dimension: 3.30" L x 1.85" W x 1.26" H (84.0mm x 47.0mm x 32.0mm)
Approvals: CE, cURus
Input Connector: IEC 320-C14
Cord Length: 59" (1.50m)
Weight: 0.243 lb (110.22g)
Description

Due to market price fluctuations, if you need to purchase or consult the price. You can contact us or emial to us:   sales@allicdata.com

AC DC Desktop, Wall Adapters – MENB1010A2403F01 Application Field and Working Principle

Adapters are a vital part of the electronics and electrical world, converting AC or DC into different voltages, currents, and frequencies so that they can be safely used for powering any given device. AC DC Desktop, wall adapters are a subcategory of power adapters and are the standard transformers devices used to plug into any appliance, such as mobile phones, computers, lamps, and a variety of other electronic devices. The MENB1010A2403F01 is a reliable AC-DC desktop, wall adapter that is commonly used to supply power in a wide range of applications. This article will further discuss the application field and working principle of the MENB1010A2403F01.

The MENB1010A2403F01 is designed to meet safety and performance requirements for input power in global markets. The adapter is equipped with an advanced design that allows for high efficiency & low ripple noise to ensure maximum reliability even in demanding environments. It is capable of supplying an output of 10W, and its rated input voltage ranges from 100-240 Volts AC at 47-63 Hz. The device also has a nominal output voltage of 24V DC. Additionally, it possesses a temperature range for proper functioning from 0 celsius up to 40 celsius, as well as a power factor value of over 0.9.

The MENB1010A2403F01 is UL, FCC, and CE certified, making it suitable for a wide range of applications, including medical, industrial, educational, and consumer electronics. In medical applications, it can be used to power medical equipment, test instruments, and other sensitive medical devices that require power continuity. For industrial applications, the adapter can be employed for powering laboratory apparatus, industrial machines, and power tools. The adapter can also be used in educational applications to power audio-visual devices, projectors, computers, and computer peripherals. In consumer electronic applications, the adapter can provide power for portable DVD players, portable DVD screens, and cordless devices.

The MENB1010A2403F01 is a reliable, efficient, and low-noise power adapter, and it is designed to ensure maximum safety. Its advanced design and rugged construction enable it to withstand harsh environmental conditions. In addition, the low ripple noise prevents any interference or noise that could affect the device\'s performance. Also, the adapter is RoHS compliant, which makes it suitable for a wide range of environmentally responsible applications.

The working principle of the MENB1010A2403F01 is simple. It utilizes an electronic power supply circuit, which is composed of various components. The main components are rectifier, filter circuit, switching power supply control, and output terminals. The rectifier section of the adapter is used to convert the input AC voltage into DC voltage. The filter circuit is used to regulate the voltage and current level of the DC voltage output by the rectifier section to ensure a stable output voltage. The switching power supply control section adjusts the input voltage to match the required output voltage. Finally, the output terminals of the adapter are used to provide the output voltage needed by the electronic device.

In conclusion, the MENB1010A2403F01 is a reliable and efficient AC-DC wall adapter that is suitable for a wide range of applications, from medical to consumer electronics. Its advanced design, robust construction, and low ripple noise enables it to function reliably even in demanding conditions. The working principle of the adapter utilizes an electronic power supply circuit to convert AC voltage into DC output voltage. These features make the adapter suitable for various applications, from medical to industrial, educational to consumer electronic.

The specific data is subject to PDF, and the above content is for reference
