Allicdata Part #: | H11AG1W-ND |
Manufacturer Part#: |
H11AG1W |
Price: | $ 0.00 |
Product Category: | Isolators |
Manufacturer: | ON Semiconductor |
Short Description: | OPTOISO 5.3KV TRANS W/BASE 6DIP |
More Detail: | Optoisolator Transistor with Base Output 5300Vrms ... |
DataSheet: | H11AG1W Datasheet/PDF |
Quantity: | 1000 |
1 +: | 0.00000 |
Series: | -- |
Packaging: | Tube |
Part Status: | Obsolete |
Number of Channels: | 1 |
Voltage - Isolation: | 5300Vrms |
Current Transfer Ratio (Min): | 100% @ 1mA |
Current Transfer Ratio (Max): | -- |
Turn On / Turn Off Time (Typ): | 5µs, 5µs |
Rise / Fall Time (Typ): | -- |
Input Type: | DC |
Output Type: | Transistor with Base |
Voltage - Output (Max): | 30V |
Current - Output / Channel: | 50mA |
Voltage - Forward (Vf) (Typ): | 1.5V (Max) |
Current - DC Forward (If) (Max): | 50mA |
Vce Saturation (Max): | 400mV |
Operating Temperature: | -55°C ~ 100°C |
Mounting Type: | Through Hole |
Package / Case: | 6-DIP (0.400", 10.16mm) |
Supplier Device Package: | 6-DIP |
Due to market price fluctuations, if you need to purchase or consult the price. You can contact us or emial to us: sales@allicdata.com
Optoisolators are components that provide electrical isolation by using a light source and a light-detecting device, such as an LED and a phototransistor. H11AG1W phototransistor opto-isolators are opto-isolator components which come with an infrared LED and an NPN Phototransistor as the output device. H11AG1W opto-isolator components are widely used in various applications due to their multiple features.
The main application fields of H11AG1W opto-isolators are electric circuits and communication networks. In electronic circuits, this component helps to protect the circuit against electrical spikes and noises. This is why H11AG1W is the most commonly used opto-isolator component for noise reduction in circuits. H11AG1W opto-isolators are also extensively used in communication networks, to provide electrical isolation between the input signal and the output signal. This helps to prevent interference between the input and output signals and ensures the safety of the communication network.
The working principle of H11AG1W opto-isolators is based on the principle of photovoltaic output. When an electrical signal is applied to the input side of the opto-isolator, the input signal is converted into a beam of light which enters the light-detecting device, such as an LED or phototransistor. The light-detecting device absorbs the light and produces an electrical signal which is fed to the output side of the opto-isolator. This output signal is isolated from the input signal, which helps to protect the circuit from electrical spikes and noise, and also prevents interference between the input and output signals.
H11AG1W opto-isolators are used in many electronic applications due to their low power consumption and easy installation. These components are also highly reliable and can withstand extreme temperatures. In addition, these components can be used to isolate high voltage signals, making them ideal for use in high voltage applications.
H11AG1W opto-isolators have a wide range of applications including electric circuits, communication networks, automotive, medical, defense, and security applications. These components are also used for controlling power supplies, data transmission, and radio frequency identification applications. These components are also widely used in industrial automation systems and are used to provide protection against electrical noise and interference.
In conclusion, H11AG1W opto-isolators are widely used in various applications due to their multiple features. These components provide electrical isolation between the input and output signals, helping to protect the circuit from electrical spikes and noises. Furthermore, these components are capable of providing electrical isolation between high voltage signals, making them ideal for use in high voltage applications.
The specific data is subject to PDF, and the above content is for reference
