254TB103B50B

Due to market price fluctuations,if you need to purchase or consult the price.You can contact us or emial to us:   sales@allicdata.com

1. Features

    1. Smallest mini-joystick available (11x11x5 mm)

    2. Long Life 1 Million Cycles

    3. Provides excellent electrical accuracy through patented mechanism

    4. Optional momentary switch is operational at all positions

    5. RoHS compliant

2. product advantages

    1. Resistance range:  10 K ohm to 100 K ohm

    2. Resistance tolerance:  ±30%, ±20%, ±10%

    3. Dielectric strength:  250 VAC 50/60 Hz for 1 minute

    4. Insulation resistance:  100 megohm @ 250 VDC 1 minute

    5. Working torque:  120±50 gf.cm

    6. Rated power:  0.0125 watts at 50°C

    7. Maximum working voltage:  50 VAC or 5 VDC maximum

    8. Switch type:  instantaneous

    9. Contact resistance：Initially max 100 milliohms 200 milliohms max after 200,000 cycles Switch 5 mA at 5 VDC

  10. Insulation resistance：Minimum 100 megohm @ 100 VDC for 1 minute

  11. Combat troops：650±150 grams force

  12. rated power：Up to 5 VDC 5 mA

  13. travel：0.6±0.2mm

  14. Switch life：200,000 cycles

3. Surface Mount Style
