| Allicdata Part #: | LEA-5A-ND |
| Manufacturer Part#: |
LEA-5A |
| Price: | $ 0.00 |
| Product Category: | RF/IF and RFID |
| Manufacturer: | U-Blox America Inc. |
| Short Description: | High-performance u-blox 5 LEA 5 series GPS/GALILEO... |
| More Detail: | N/A |
| DataSheet: |  LEA-5A Datasheet/PDF |
| Quantity: | 1000 |
| Series: | LEA-5A |
| Packaging: | Tape & Reel (TR) |
| Part Status: | Active |
| Frequency: | -- |
| Sensitivity: | -- |
| Data Rate (Max): | -- |
| Modulation or Protocol: | -- |
| Applications: | -- |
| Current - Receiving: | -- |
| Data Interface: | -- |
| Memory Size: | -- |
| Antenna Connector: | -- |
| Features: | -- |
| Voltage - Supply: | 2.7V ~ 3.6V |
| Operating Temperature: | -40°C ~ 85°C |
| Package / Case: | -- |
| Supplier Device Package: | -- |
| Base Part Number: | LEA-5A |
Due to market price fluctuations,if you need to purchase or consult the price.You can contact us or emial to us: sales@allicdata.com
1. Description
u-blox's LEA-5 module series sets new standards for GPS and GALILEO receiver modules. With high-performance 50-channel u-blox 5 technology, these modules have outstanding performance and flexibility At an economical price. A 32-channel acquisition engine with more than one million effective correlators can Massively parallel search. This allows the time to first repair (TTFF) to be less than 1 second, and the long correlation/dwell time makes best-in-class capture and tracking sensitivity possible. One available This function is KickStart, which is a new function that can speed up the collection of weak signals. Once acquired, the satellite will be passed to a dedicated tracking engine optimized for power. This arrangement allows GPS and The GALILEO engine can track up to 16 satellites when searching for new satellites. u-blox 5's advanced interference suppression mechanism and innovative RF architecture can provide a high degree of anti-interference ability to ensure the highest GPS and GALILEO performance. The LEA-5 series maintains the highly successful LEA-4 module with a compact size of 17.0 x 22.4 mm. The design of this module takes into account backward compatibility, which simplifies upgrades and reduces engineering and design costs. The USB port can provide faster data transfer and greater flexibility.
2. Feature
1. 50-channel u-blox 5 engine with more than one million effective correlators
2. The first repair of hot start and auxiliary start time is less than 1 second
3. -160dBmSuperSense® Sensitivity
4. Through the KickStart function to accelerate the start with a weak signal
5. Up to four serial interfaces: 1 UART, 1 USB, 1 DDC (I2C compliant), 1 SPI (if any)
6. Support AssistNowOnline and AssistNowOffline A-GPS services; comply with OMA SUPL
7. Strong anti-interference ability
8. Hybrid GPS, GALILEO and SBAS (WAAS, EGNOS, MSAS, GAGAN) engines
9. 4 Hz position update rate
10. Easy migration from LEA-4 module
11. RoHS compliant
3. Product features
